Low Energy Buildings Projects

Click on image to preview full size

Energy target

Measured data from renewable generation is not yet available.

Electricity generation	Forecast	Measured
Renewables Technology	-	-
Other Renewables Tech	-	-
Electricity consumed by generation	-	-
Primary energy requirement offset by renewable generation	-	-
Annual CO₂ emissions offset by renewable generation	-	-

Whole house energy calculation method	PHPP
Other whole house calculation method	-
Energy target	Retrofit for the Future
Other energy targets	-
Forecast heating load	12 W/m² demand

	Date	Result
Pre-development air permeability test	-	12.32m³/m².hr @ 50 Pascals
Final air permeability test	-	6.46m³/m².hr @ 50 Pascals

Stage	Under construction
Start date	03 May 2010
Occupation date	06 September 2010
Location	Newcastle upon Tyne England
Build type	Refurbishment
Building sector	Public Residential
Property type	Semi-Detached
Construction type	Masonry Cavity
Other construction type	50mm cavity width
Party wall construction	250mm solid brick
Floor area	99.8 m²
Floor area calculation method	Treated Floor Area (PHPP)
Building certification

Organisation	Newcastle City Council
Project lead person	Newcastle City Council
Landlord or Client	Your Homes Newcastle / Newcastle City Council
Architect	DKS Architects / Newcastle City Council
Mechanical & electrical consultant	ARUP
Energy consultant	Vanguard Homes / ARUP
Structural engineer	Vanguard Homes / Newcastle City Council
Quantity surveyor	Vanguard Homes / Newcastle City Council
Consultant	Institute of Energy and Sustainable Development, De Montfort University
Contractor	t.b.d.

Planned occupancy	Advertised as Passive House with incentives to attract willing family tenant. Proposed as decant unit to act as education / demonstration through occupany.
Space heating strategy	MVHR unit with backup mains gas.
Water heating strategy	Solar water heating.
Fuel strategy	Mains gas and electricity
Renewable energy strategy	No requirement for renewable electricity to meet Passive House standard.
Passive Solar strategy	Rear south facing windows with shading / external landscaping.
Space cooling strategy	Natural ventilation combined with MVHR unit for summer cooling.
Daylighting strategy	Kitchen to achieve minimum daylight factor of 2%
Ventilation strategy	Openable windows and MVHR controlled on a room by room basis.
Airtightness strategy	External airtight membrane colocated with with external insulation layer. MMC used in bays and pre fitted replacement windows panels.
Strategy for minimising thermal bridges	External insulated panel with overlapping layers and taped joints.
Modelling strategy	Whole house modelling in PHPP 2007. Phased assessment based upon proposed sequence of interventions.
Insulation strategy	External insulation to external brick facing to achieve U-value of 0.12 W/m2K. Ceiling insulation with U-value of 0.12 W/m2K and retention of cold roof.
Other relevant retrofit strategies
Contextual information	Proposed work in advance of wider retrofit programme for the estate and informed by transferable detailing, materials and scalign of cost benefits.

Occupancy	NULL
Space heating	NULL
Hot water	NULL
Ventilation	NULL
Controls	NULL
Cooking	NULL
Lighting	NULL
Appliances	NULL
Renewable energy generation system	NULL
Strategy for minimising thermal bridges	NULL

Storeys
Volume	-
Thermal fabric area	-
Roof description	NULL
Roof U-value	0.00 W/m² K
Walls description	NULL
Walls U-value	0.00 W/m² K
Party walls description	NULL
Party walls U-value	0.00 W/m² K
Floor description	NULL
Floor U-value	0.00 W/m² K
Glazed doors description	NULL
Glazed doors U-value	0.00 W/m² K -
Opaque doors description	NULL
Opaque doors U-value	0.00 W/m² K -
Windows description	NULL
Windows U-value	0.00 W/m² K -
Windows energy transmittance (G-value)	-
Windows light transmittance	-
Rooflights description	NULL
Rooflights light transmittance	-
Rooflights U-value	0.00 W/m² K
